BHZ93420-III HART Liquid Level Transmitter 0-400m Range IP68

Certification : CE, RoHS, ISO9001

MOQ : 1

Price : 40

Pressure Range : 0-1m-400m

Display Type : LED

Accuracy Grade : 0.1%,0.25%

IP Rating : IP68

Net Weight : 1.6kg

Diaphragm Material : 316L Stainless Steel

Measurement Range : 0~10m…400m

Pressure Type : Gauge Pressure, Absolute Pressure, Sealed Pressure

Overload Capacity : ≤ 2X rated range

Operating Temperature : -20~80ºC

Storage Temperature : -30~100ºC

Housing Material : Cast aluminum, Stainless steel 1Cr18Ni9Ti

Insulation Resistance : >=100MΩ@100VDC

Explosion-proof Rating : ExiaIICT6

Output Signal : 4~20mA with Hart

Contact Now

BHZ93420 III Liquid level Transmitter

Introduction:
BHZ93420-III insertion-type intelligent liquid level transmitter is equipped with a high-precision piezoresistive silicon pressure sensor as its signal measuring element. It measures the static pressure, which is directly proportional to the liquid level. The transmitter utilizes HART communication protocol to achieve digital signal transmission and two-way communication

Product Features:

HART communication protocol output, with display capability
High accuracy and excellent stability
Explosion-proof rating : ExiaIICT6
High protection level, IP68
PE, PTFT, PU cables available

Applications:

Compatible with 316LSS,noncorrosive liquids
Monitoring water levels in various applications such as sewage, industrial and municipal water, water tanks, wells, rivers, seawater, lakes, etc
Diesel, fuel, and other oil tank level monitoring

Performance Parameters
Measurement Range	0~10m…400m
Pressure Type	Gauge Pressure, Absolute Pressure, Sealed Pressure
Overload	≤ 2X rated range
Accuracy @ 25ºC	±0.1% (Typ.) ±0.2% (Max.)
Repeatability	±0.03% (Typ.) ±0.05%FS (Max.)
Hysteresis	±0.03% (Typ.) ±0.05%FS (Max.)
Long-Term Stability	±0.15%F.S/year (Max.)
Zero Temperature Drift	±0.01%FS/ºC(>100KPa), ±0.02%FS/ºC (≤100Kpa)
Span Temperature Drift	±0.01%FS/ºC(>100KPa), ±0.02%FS/ºC (≤100Kpa)
Compensation Temperature	0-50ºC (0-1m . 0-2m); 0-70ºC
Operating Temperature	-20~80ºC
Storage Temperature	-30~100ºC
Vibration	10g,55Hz ~ 2kHz
Shock	100g
Housing Material	Cast aluminum, Stainless steel 1Cr18Ni9Ti
Diaphragm Material	316L Stainless Steel
Insulation Resistance	>=100MΩ@100VDC
Explosion-proof Rating	ExiaIICT6
Protection Rating	IP68
O-Ring Seal	Fluoro rubber
Weight	~1.6Kg (without cable)
Cable Material	Polyethylene, Polyurethane, PTFE cable

Output Signal	Supply Voltage	Output Type
4~20mA with Hart	15~30VDC	2 wire

Electrical Connection
	4-20mA (HART)	1	V+	Red
		2	V-	Yellow
		3	NC
		4	NC
	4-20mA (HART)	1	V+	Red
		2	V-	Yellow
		3	NC
		4	NC
	4-20mA (HART)	1	V+	Red
		2	V-	Yellow
		3	GND
		4	NC

Order Guide
BHZ93420	Code	Outline Construction
	III	Intelligent liquid level transmitter
		Measurement Range		0~10m…400m
			Code	Power Supply
			D1	24VDC
				Code	Output Signal
				S1	4~20mADC			S2		4~20mADC with Hart
					Code	Electrical Connection
					B4	2088 with display
					B5	3051
					B6	3051A
						Code	Pressure Type
						G	Gauge Pressure
						A	Absolute Pressure
						S	Sealed Reference Pressure
							Code		Cable Material
							C1		PE
							C2		PU
							C3		PTFE

BHZ93420-III HART Liquid Level Transmitter 0-400m Range IP68

FAQ:
1. Q: What are the features of your pressure sensor transmitters?
A: High precision, durability, and excellent performance. Customization available.
2. Q: Can I customize special specifications?
A: Yes, our engineers can tailor products to meet specific needs. We provide OEM and ODM service
3. Q: What is your production capacity?
A: Our manufacturing facilities can produce up to 30,000 pressure sensor transmitters per month, so we are fully capable of meeting the needs of large-scale orders. However, it is advisable to contact our sales team in advance to ensure smooth production and delivery scheduling.
4. Q: What's the typical delivery period?
A: 5~8 working day for standard models. Customized products may vary.
5. Q: How are the products priced? Any discounts?
A: Competitive pricing with discounts for bulk orders or long-term partners.
6. Q: What is the warranty of your products? And after-sales service?
A: Our warranty time is 24 months after shipment, and our after-sales will respond with your questions in 24hrs, remote instruction by PC network is always available.
